MM W4400 NR
MM W4400 NR
| Model | MM W4400 NR | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| MM W4400 NR |
Power/RPM kW/RPM (hp/RPM) |
Maximum rated input kW (hp) |
Ratio | Maximum input RPM | ||||||
| 0,540 (0,724) | 1242 (1665) | 3,026 | 2300 | |||||||
| 3,486 | ||||||||||
| 4,032 | ||||||||||
| 4,448 | ||||||||||
| 5,077 | ||||||||||
| 5,542 | ||||||||||
| 5,913 | ||||||||||
| Dry weight kg(lb) | 1270 (2800) | |||||||||
| SAE bell | #0, #1 | |||||||||
| Type | Vertical offset | |||||||||
| Kinematics | Reversible or Non-Reversible (Engine-Wise or Counter-Engine-Wise) | |||||||||
Description
- Robust design and easy onboard maintenance.
- Robust design also withstands continuous duty in workboat,dredger applications.
- Fully works tested, reliable and simple to install.
- Reverse reduction marine transmission with hydraulically actuated multi-disc clutches.
- Case hardened and precisely ground gear teeth for long life and smooth running.
- Robust cast iron casing for direct or remote mounting.
- Emergency “get home” capability.
- Design, manufacture and quality control standards comply with ISO.
- Suitable for twin installation with 100% rated power in ahead and astern condition.
